7
IT-ENProgrammazione • Programming MICRO SWITCH
Individuare la casa automobilistica e il modello della
propria vettura, successivamente impostare gli inter
-
ruttori lato sinistro come indicato:
Select the car manufacturer and model of your car,
then set the switches on the left side as shown below:
IT EN
TOYOTA DIPSWITCH SETTING CONNECTION CABLE
4 Runner 03>14
Auris 07>14
Avensis T25 03>08
Corolla E12 01>14
Land Cruiser 03>10
Matrix 09>14
Prius 04>14
Prius C 14
Prius+ 12>14
Rav4 AACA ACE 06>10
Rav4 10>14
Yaris 06>14
DIP ON
1 2 3 4 5 6 7 8
NERO / BLACK
BIANCO / WHITE
BIANCO-NERO
WHITE-BLACK
20 POLI / POLES
CONNETTORE 6+4 POLI
6+4 POLES CONNECTOR
ACC +12 V
GROUND
BATTERY
