Phonocar 04041 - Page 9

9
IT-ENImpostostazioni autoradio • Car radio settings
DIPSWITCH ADAPTATOR CABLE
ONDIP
1 2 3 4
BLAUPUNKT
KEY 1/A SWC1
KEY 2/B SWC2
KEY GROUND
VIOLA/PURPLE
MARRONE/BROWN
NERO/BLACK
RESISTIVE
ONDIP
1 2 3 4
CLARION
DO NOT CONNECT
NON COLLEGARE
KENWOOD
ONDIP
1 2 3 4
JVC >2011
DO NOT CONNECT
NON COLLEGARE
ONDIP
1 2 3 4
JVC 2011>
DO NOT CONNECT
NON COLLEGARE
DIPSWITCH ADAPTATOR CABLE
ONDIP
1 2 3 4
PHONOCAR
KEY 1/A SWC1
KEY 2/B SWC2
KEY GROUND
VIOLA/PURPLE
MARRONE/BROWN
NERO/BLACK
RESISTIVE
ONDIP
1 2 3 4
PIONEER
DO NOT CONNECT
NON COLLEGARE
KENWOOD
ONDIP
1 2 3 4
SONY
DO NOT CONNECT
NON COLLEGARE
ONDIP
1 2 3 4
UNIVERSAL
KEY 1/A SWC1
KEY 2/B SWC2
KEY GROUND
VIOLA/PURPLE
MARRONE/BROWN
NERO/BLACK
RESISTIVE
