Doc.No.: 99400-000-DE
Page 12 of 14
.
PHONTECH
7. TECHNICAL DATA. TELEPHONE UNITS 4050/4051/4060/4061
Dimensions flush mounting:
240 x 144 x 70 mm. (h x w x d)
Cut- out measurement flush mounting:
212 x 116 mm. (h x w)
Dimensions wall mounting wall mounting box included:
242 x 146 x 73 mm. (h x w x d)
Type 4050/51/60/61: add 78 mm to depth for handset.
Weight flush mounted: 1,4 kg.
Weight wall mounted: 1,8 kg.
Operation voltage 24 VDC (optional)
Ingress protection: IP 44.
Technical data for substations etc., see data sheets for each unit.
TECHNICAL DATA. WP TELEPHONE UNIT 4055.
Dimensions flush mounting:
240 x 144 x 70 mm. (h x w x d)
Cut- out measurement flush mounting:
212 x 116 mm. (h x w)
Dimensions wall mounting wall mounting box included:
242 x 146 x 73 mm. (h x w x d)
Type 4055: add 115 mm to depth for handset.
Weight flush mounted: 1,4 kg.
Weight wall mounted: 1,8 kg.
Operation voltage 24 VDC (optional)
Ingress protection: IP 44.
