RELAY SWITCH BOARD FOR BATTERYLESS SYSTEM
99400-001-CD
DESCRIPTION
The Batteryless Telephone Board 99400-001 is designed and produced by phonTECH communication
a/s, Horten in Norway.
The board is a plug-in module supporting switching facility for external signal device in the batteryless
telephone system.
Switching capacity:
24 VDC: 150 VA
115 VAC: 700 VA
220 VAC: 1500 VA
Operation voltage:
Relay coil: 24 VDC
