Doc.No.: 99400-000-DE
01 18.01.2002 REVISION EM -904 TBA RS TBA
0 09.05.2001 FINAL DOCUMENTATION TLY TBA TLY
REV No: ISSUE DATE REASON FOR ISSUE PREPARED CHECKED APPROVED
This document is the property of PHONTECH and
must not be copied or shown to a third person
without our written acceptance. In the interest of
product improvement, PHONTECH reserves the
right to alter specification and design without
notice.
SIZE: A4 UED no: M002
DOC no: 99400-000-DE
BATTERYLESS TELEPHONE SYSTEM
DESCRIPTION
FILE NAME: 99400-000-DE
V:\prosjekt\SERIE\4\4050-51-56-57-60-61 fellesdokumenter\desc\99400-000-DE.doc
Page 1 of 14
PHONTECH
BATTERYLESS TELEPHONE SYSTEM 4000
SERIES 4050/4051/4055/4060/4061.
SYSTEM DESCRIPTION.
LIST OF CONTENTS: page
1. GENERAL DESCRIPTION 2
2. LIST OF TELEPHONE UNITS 3
3. ADDITIONAL EQUIPMENT 4
4. LIST OF FACILITIES 7
5. BASIC MEANS OF OPERATION 8
6. INSTALLATION 10
• SYSTEM CONFIGURATION
• MOUNTING
• CABLE TERMINATION
• CABLE REQUIREMENTS
• GLANDING
• SCREENING
• FERRULING
• MARKING
• FASTENING
• PRESERVATION
• VOLUME ADJUSTMENT
7. TECHNICAL DATA 12
8. SINGLE LINE DIAGRAM - 12 LINE SYSTEM 13
9. SINGLE LINE DIAGRAM - SINGLE LINE SYSTEM 14
