Installation manual PMCprimo Drive2
7.9.3 Conductor cross-sections
Following EN 60204 (for AWG: table 310-16 of the NEC 60°C or 75°C column), we recommend:
AC connection PMCprimo Drive2 sz. 01-10 : 1,5 mm²
PMCprimo Drive2 sz. 14/20 : 4 mm²
600V, 105°C, twisted
DC-link PMCprimo Drive2 sz. 01-10 : 1,5 mm²
PMCprimo Drive2 sz 14/20 : 4 mm²
shielded for length >
20 cm
Motor cables up to 25 m length PMCprimo Drive2 sz. 01-10 : 1 - 1,5mm²
PMCprimo Drive2 sz. 14/20 : 2,5 mm²
shielded,
capacitance<150pF/m
Motor cables 25 to 100 m length
PMCprimo Drive2 sz. 01-10 : 1 mm²
PMCprimo Drive2 sz. 14/20 : 2,5 mm²
shielded with motor
choke MD400
Resolver, thermostat-motor 8x0.25 mm² twisted pairs, shielded, max.100m,
capacitance <120pF/m
HIPERFACE Encoder, thermostat-
motor
10x0.14 mm² twisted pairs, shielded, max.100m,
capacitance <120pF/m
Analog In- and outputs, AGND 0.25 mm² , twisted pairs, shielded
Control signals, BTB, DGND 0.5 mm²
Holding brake (Motor) min. 0.75 mm², shielded, check voltage drop
+24 V / XGND max. 2.5 mm², check voltage drop
24 V (X10) EGND / VCC Enc. Max. 1 mm
2
, check voltage drop
7.9.4 LED-Display
A 3-character LED displays the servo amplifiers firmware version after switching on the 24V supply
for two seconds (e.g. “2.46”).
Afterwards the status of up to 10 axes is shown (or just “run”).
When an error occurs the error number is displayed (⇒ S. 83 ).
