Pioneer A-209R - Ac Primary Assy

A-209R, A-209
11
A
B
C
D
1
234
1
2
3
4
C
3.4 AC PRIMARY ASSY
C
AC PRIMARY ASSY
AWX7113 (MYXJ, MVXJ, MLXJ)
AWX7670 (SBDXJ)
SBDXJ type
MYXJ,
MVXJ,
MLXJ types
SBDXJ type
MYXJ, MVXJ, MLXJ types
REK1023
T1.25AL250V
REK1023
T1.25AL250V
S801
ASG1035
LIVE
NEUTRAL
TO POWER
TRANSFORMER
TO
AC POWER
CORD
TO S2
VOLTAGE
SELECTOR
• NOTE FOR FUSE REPLACEMENT
FOR CONTINUED PROTECTION AGAINST RISK OF FIRE.
REPLACE WITH SAME TYPE AND RATINGS ONLY.
CAUTION -
POWER
A-209/SBDXJ
