Specifications
General
Power source ............................. 14.4 V DC (10.8 V to 15.1 V
allowable)
Grounding system ................... Negative type
Max. current consumption
..................................................... 2.0 A
Dimensions (W × H × D):
DIN
Chassis ..................... 178 mm × 50 mm × 164
mm
(7 in. × 2 in. × 6-1/2 in.)
Nose ........................... 188 mm × 58 mm × 18 mm
(7-3/8 in.× 2-1/4 in.× 3/4 in.)
D
Chassis ..................... 178 mm × 50 mm × 164
mm
(7 in.× 2 in.× 6-1/2 in.)
Nose ........................... 170 mm × 45 mm × 18 mm
(6-3/4 in.× 1-3/4 in.× 3/4 in.)
Weight .......................................... 1.6 kg (3.5 lbs)
Audio/DSP
Preout max output level ....... 5.0 V
Loudness contour ................... +10 dB (100 Hz), +6.5 dB
(10 kHz) (volume: –30 dB)
Equalizer (Left/Right independent 31-Band Graphic
Equalizer):
Frequency .......................... 20/25/31.5/40/50/63/80/100/
125/160/200/250/315/400/
500/630/800/1k/1.25k/1.6k/
2k/2.5k/3.15k/4k/5k/6.3k/8k/
10k/12.5k/16k/20k Hz
Equalization range ........ ±12 dB (0.5 dB step)
Time alignment ........................ 0 cm to 394.24 cm (0.77 cm/
step), 0 inch to 155.392 inch
(0.3035 inch/step)
Network (Left/Right independent):
High:
LPF
Frequency ................ 5k/6.3k/8k/10k/12.5k/16k/20k
Hz
Slope .......................... PASS, –6/–12/–18/–24/–30/
–36 dB/oct
Gain ............................ 0 dB to –24 dB/Mute (1 dB
step)
Phase ........................ Normal/Reverse
HPF
Frequency ................ 800/1k/1.25k/1.6k/2k/2.5k/
3.15k/4k/5k/6.3k/8k/10k/
12.5k/16k Hz
Slope .......................... –6/–12/–18/–24/–30/–36 dB/
oct
Gain ............................ 0 dB to –24 dB/Mute (1 dB
step)
Phase ........................ Normal/Reverse
Mid:
HPF/LPF
Frequency (LPF) ... 25/31.5/40/50/63/80/100/125/
160/200/250/315/400/500/
630/800/1k/1.25k/1.6k/2k/
2.5k/3.15k/4k/5k/6.3k/8k/
10k/12.5k/16k/20k Hz
Frequency (HPF)
................................. 20/25/31.5/40/50/63/80/100/
125/160/200/250/315/400/
500/630/800/1k/1.25k/1.6k/
2k/2.5k/3.15k/4k/5k/6.3k/8k/
10k/12.5k/16k Hz
Slope (LPF) ............. PASS, –6/–12/–18/–24/–30/
–36 dB/oct
Slope (HPF) ............ PASS, –6/–12/– 18/–24/–30/
–36 dB/oct
Gain ............................ 0 dB to –24 dB/Mute (1 dB
step)
Phase ........................ Normal/Reverse
Low:
HPF/LPF
Frequency (LPF) ... 25/31.5/40/50/63/80/100/125/
160/200/250/315/400/500/
630/800/1k/1.25k/1.6k/2k/
2.5k/3.15k/4k/5k/6.3k/8k/
10k/12.5k/16k/20k Hz
Frequency (HPF)
................................. 20/25/31.5/40/50/63/80/100/
125/160/200/250/315/400/
500/630/800/1k/1.25k/1.6k/
2k/2.5k/3.15k/4k/5k/6.3k/8k/
10k/12.5k/16k Hz
Slope (LPF) ............. PASS, –6/–12/–18/–24/–30/
–36 dB/oct
Slope (HPF) ............ PASS, –6/–12/– 18/–24/–30/
–36 dB/oct
Gain ............................ +6 dB to –24 dB/Mute (1
dB step)
Phase ........................ Normal/Reverse
Additional Information
En
75
Appendix
Additional Information
