C) CARTON BOX, CUSHION
PK15
ACCESSORY BOX(42VP4)
29MS2471
PK09 CUSHION(TL)
29MS2411
PK13 CUSHION(BC)
29MS2451
PK16 CARTON BOX(T)(424MV)
29MS3281 : /PDP-424MV
29MS3291 : /PDP-42MVE1
PK10 CUSHION(TR)
29MS2421
PK08 PROTECTION SHEET
29M00481
PK12 CUSHION(BR)
29MS2441
PK14 CARTON BOX(B)
29MS2461
PK11 CUSHION(BL)
29MS2431
PROTECTION SHEET
After adhesion with a tape, the direction
shall be corrected for accommodation.
Positioned on the left as seen
from the front so that the usage
arrow mark face the front plane
of the set.
Positioned on the left as seen
from the front so that the usage
arrow mark face the front plane
of the set.
Positioned on the right as seen
from the front so that the usage
arrow mark face the front plane
of the set.
Positioned on the right as seen
from the front so that the usage
arrow mark face the front plane
of the set.
Positioned so that the
arrow mark faces the
front plane of the set.
To be folded inside
(4 positions)
To be laid and wrapped beneath
the set
Rear Side
Fastened with a tape in 5 positions.
The ashesive tape to be used is:
Paper adhesive tape 30 mm*18mm:
92203227 or Paper adhesive tape
19mm*18mm: 92203226
PK25
WARRANTY ENVELOPE(100x220)
