Pioneer PDP-436SXE Service Manual

PDP-436SXE
53
5678
56
7
8
C
D
F
A
B
E
AUDIO ASSY
SEMICONDUCTORS
IC3754 BR24L02FJ-W
IC3751 LA4625
IC3753 NJW1183GK1
IC3752 PQ09DZ11
Q3751, Q3754, Q3755, Q3757 2SA1586
Q3756, Q3759 2SC4116
Q3758, Q3760 DTC124EUA
D3751 1SS355
COILS AND FILTERS
>
L3901, L3902 LINE FILTER ATF1206
CAPACITORS
C3917, C3918 (1.5/63) ACH1420
C3756 (1/25) BCG1060
C3765, C3768 CCSRCH101J50
>
C3906, C3908, C3914, C3916 CCSRCH101J50
C3901, C3902, C3909, C3910 CCSRCH221J50
C3775, C3777, C3788, C3790, C3791 CEHAT100M50
C3799 CEHAT100M50
C3761, C3764, C3786, C3798 CEHAT101M16
C3766, C3780, C3783-C3785, C3797 CEHAT1R0M50
C3808, C3812, C3814 CEHAT1R0M50
C3762 CEHAT220M50
C3752, C3753 CEHAT2R2M50
C3759 CEHAT331M16
C3757 CEHAT471M25
C3755 CEHAT472M25
C3763 CEHAT4R7M50
C3754, C3805 CFTLA103J50
C3767, C3770, C3772-C3774 CFTLA104J50
C3781, C3782, C3789, C3792-C3795 CFTLA104J50
C3806, C3807, C3813 CFTLA104J50
C3811 CFTLA223J50
C3778 CFTLA334J50
C3758, C3760, C3796 CKSRYB103K50
C3769, C3815 CKSRYB222K50
C3903, C3911 CKSRYB332K50
C3779 CKSRYB822K50
C3816 CKSRYF104Z16
C3904, C3912 CKSRYF473Z50
RESISTORS
R3901-R3904 RD1/2MMF100J
R3768-R3770, R3782 RD1/2MMF2R2J
Other Resistors RS1/16S###J
OTHERS
CN3751 CONNECTOR B3P-VH
CN3901 8P TOP POST B8B-EH
3772, 3773 SCREW PMB30P100FNI
3774, 3775 SCREW VBB30P100FNI
KN3751, KN3752 WRAPPING TERMINAL VNF1084
SR ASSY
SEMICONDUCTORS
IC7601 MAX3232CPW
Q7608 HN1B04FU
Mark No. Description Part No.
TH7601 TH05-3H103F
CAPACITORS
C7608 CEHVKW100M16
C7601 CKSRYB103K50
C7603-C7607, C7614 CKSSYF104Z16
RESISTORS
R7626 RS1/16S4701F
R7602-R7605 RS1/16SS###J
Other Resistors RS1/16S###J
OTHERS
CN7602 9P D-SUB SOCKET AKP1213
7602 SCREW TERMINAL VNE1949
TUNER ASSY
SEMICONDUCTORS
IC4401 MSP3417G
Q4402 2SC4116
Q4410, Q4415 DTC124EUA
Q4407, Q4408 HN1A01FU
Q4409 HN1C01FU
D4403 UDZS8R2(B)
COILS AND FILTERS
L4401-L4403 CHIP COIL BTH1119
L4405, L4406 LCTAW150J2520
L4407 LCTAW4R7J2520
L4404 LCTAW8R2J2520
F4401, F4402 VTF1080
SWITCHES AND RELAYS
S4401 ASG1100
CAPACITORS
C4404, C4407, C4415, C4429 (10/6.3) ACG7046
C4424 (3.3/50) ACH1385
C4449 CCSRCH680J50
C4442 CCSRCJ3R0C50
C4417, C4418 CCSSCH100D50
C4450 CCSSCH121J50
C4456 CCSSCH181J50
C4448 CCSSCH470J50
C4428, C4443 CCSSCH560J50
C4441 CCSSCH5R0D50
C4409, C4423 CEHVKW100M16
C4421 CEHVKW101M6R3
C4422 CEHVKW470M16
C4411, C4413 CKSRYF104Z50
C4403, C4406, C4410, C4430, C4440 CKSSYB102K50
C4444, C4455, C4461 CKSSYB102K50
C4408, C4439, C4446 CKSSYB103K16
C4438, C4454 CKSSYB472K25
C4402, C4405, C4425, C4426, C4432 CKSSYF104Z16
C4434, C4435, C4447, C4451, C4460 CKSSYF104Z16
C4465 CKSSYF104Z16
C4414, C4437, C4445 (10/16) DCH1165
RESISTORS
R4407-R4409, R4431, R4441, R4443 RS1/16S###J
R4446, R4451, R4455-R4457, R4461 RS1/16S###J
R4462 RS1/16S###J
Mark No. Description Part No.
