Page #37 background image
PDP-5000EX
37
5678
56
7
8
C
D
F
A
B
E
• Block Name: DIGITAL DD CON BLOCK
MISCELLANEOUS
U 3801 AXY1138
RESISTORS
R 3801 RAB4C101J
R 3837,3838 RS1/16S0R0J
Other Resistors RS1/16SS###J
CAPACITORS
C 3804 CKSSYB102K50
Unit Name: PANEL SENSOR ASSY
SEMICONDUCTORS
IC 3901 MM1522XU
IC 3902 BR24L02FJ-W
Q 3901 HN1B04FU
MISCELLANEOUS
CN3901 CONNECTOR AKM1276
All Resistors RS1/16SS###J
CAPACITORS
C 3901,3902 CKSSYB104K10
C 3903,3904 CKSSYB103K16
C 3906,3907 CKSRYB105K6R3
Mark No. Description Part No.
