Pioneer PDP-507XA User Manual

PDP-507XD
74
1234
1234
C
D
F
A
B
E
CN3506 (D20) ↔ 50 Y MAIN DRIVE ASSY CN2001 (Y1)
Pin No. Pin Name I/O Function Voltage (V) TP
40 PSW2 O Function standby control signal
39 YDRV_PD I Y drive PD signal
38 SCAN_PD I Y drive PD signal 0 to 3.3
0 to 3.3
0 to 3.3
0 to 3.3
0 to 3.3
–
–
–
0 to 3.3
0 to 3.3
0 to 3.3
0 to 3.3
0 to 3.3
0 to 3.3
–
0 to 3.3
0 to 3.3
0 to 3.3
–
0 to 3.3
–
0 to 3.3
0 to 3.3
0 to 3.3
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
37 YSUS_PD I Y drive PD signal
36 YDD_PD I Y drive PD signal
35 GND – GND –
34 GND – GND –
33 GND – GND
32 GND – GND
31 VYPRST_ADJ O Y drive control signal 0 to 3.3
30 VOFS_ADJ O Y drive control signal 0 to 3.3
29 GND – GND
28 YSOFT-D O Y drive control signal
27 YRsv3 O Y drive control signal
26 YNOFS O Y drive control signal 0 to 3.3
25 GND – GND –
24 YRsv2 O Y drive control signal
23 YNRST O Y drive control signal
22 YSUS_MSK O Y drive control signal
21 GND – GND –
20 SUS_MUTE O Y drive control signal 0 to 3.3
19 YPR-U O Y drive control signal
18 GND – GND
17 YSUS_G O Y drive control signal
16 YSUS_D O Y drive control signal 0 to 3.3
15 GND – GND –
14 YSUS_U O Y drive control signal
13 YSUS_B O Y drive control signal
12 GND – GND
11 OC1 (–1) O Scan control signal 0 to 3.3
10 OC2 O Scan control signal 0 to 3.3
9LEOScan control signal
8 GND – GND
7 CLK1 O Scan control signal
6 CLR O Scan control signal 0 to 3.3
5 GND – GND –
4 SI_H O Scan control signal
3 SI_L O Scan control signal 0 to 3.3
2 SCN5V_PD I Scan 5 V PD signal 0 to 3.3
1 YCN_PD O Y drive PD signal

Pioneer PDP-507XA Specifications

General

3D	-
Depth	115 mm
Width	1224 mm
Height	717 mm
Weight	34100 g
Tuner type	Analog
Pixel pitch	- mm
Smart modes	Energy saving
Aspect ratio	16:9
Product color	Black
LED indicators	Y, Power
Noise reduction	Yes
RMS rated power	26 W
AC input voltage	220 - 240 V
Display diagonal	50 \
Channels quantity	99 channels
AC input frequency	50 - 60 Hz
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Number of speakers	2
Teletext standards	Top-text
SCART ports quantity	3
Supported video modes	1080p
USB 2.0 ports quantity	0
Contrast ratio (typical)	4000:1
Annual energy consumption	- kWh
Display diagonal (metric)	127 cm
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL BG, PAL DK, PAL I, SECAM, SECAM B/G, SECAM D/K, SECAM L
Power consumption (standby)	0.3 W
Power consumption (typical)	341 W
Sound enhancement technology	FOCUS, SRS, TruBass
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Component video (YPbPr/YCbCr) in	1
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE, TUR
