Speaker
You can make changes to the connection environment of the speakers and change the
volume level. Settings are automatically configured if you use Full Auto MCACC. This
setting cannot be selected if headphones are connected or audio is output from the
speakers of the TV.
■ Configuration
Setting Item Default Value Setting Details
Speaker
Channels
7.1.2 ch Select "2.1 ch", "3.1 ch", "4.1 ch", "5.1 ch", "6.1
ch", "7.1 ch", "2.1.2 ch", "3.1.2 ch", "4.1.2 ch",
"5.1.2 ch", "6.1.2 ch", "7.1.2 ch", "4.1.4 ch", "5.1.4
ch", "6.1.4 ch", or "7.1.4 ch" to suit the number of
speaker channels connected.
•
This unit consists of a 9 ch amplifier, so with
"6.1.4 ch" or "7.1.4 ch" selected, use an analog
audio cable to connect the power amplifier to
the PRE OUT SURR BACK jacks on this unit,
then connect the surround back speakers to the
power amplifier.
Subwoofer 2ch Set the PRE OUT SUBWOOFER jacks which
output audio signals.
"1ch": Only the PRE OUT SUBWOOFER 1 jacks
output audio signals.
"2ch": Both the PRE OUT SUBWOOFER 1 jacks
and the PRE OUT SUBWOOFER 2 jacks output
audio signals.
"No": Neither the PRE OUT SUBWOOFER 1 jacks
nor the PRE OUT SUBWOOFER 2 jacks output
audio signals.
Setting Item Default Value Setting Details
Height 1 Speaker Top Middle Set the speaker type if height speakers are
connected to the HEIGHT 1 terminals. Select
"Front High", "Top Front", "Top Middle", "Top
Rear", "Rear High", "Dolby Speaker (Front)",
"Dolby Speaker (Surr)", or "Dolby Speaker (Back)"
according to the type and layout of the connected
speakers.
•
This setting cannot be selected under any of
following conditions. Set the height speakers
type to "Height 2 Speaker".
–
"System Setup" - "Speaker" - "Configuration"
- "Bi-Amp" is set to "Front"
–
"System Setup" - "Speaker" - "Configuration"
- "Zone Speaker" is set to "Zone 2/Zone 3"
•
When two sets of height speakers are being
used, "Top Rear", "Rear High", "Dolby Speaker
(Surr)", and "Dolby Speaker (Back)" cannot be
selected
•
"Dolby Speaker (Surr)" and "Dolby Speaker
(Back)" can only be selected when surround
speakers or surround back speakers are being
used, respectively. You can check speakers that
you are using on the figure displayed in "System
Setup" - "Speaker" - "Configuration" - "Speaker
Channels".
•
If an item cannot be selected even though
connection is correct, check that the settings in
"System Setup" - "Speaker" - "Configuration"
- "Speaker Channels" matches the number of
connected channels.

Pioneer SC-LX701 Specifications

General

Display	-
Product color	Silver
Audio decoders	DTS 96/24, DTS-ES, DTS-HD, DTS-HD HR, DTS-HD Master Audio, Dolby Digital Plus, Dolby Surround, Dolby TrueHD
Audio amplifier	Yes
Apple docking compatibility	Not supported
Receiver type	Surround
Frequency range	20 - 20000 Hz
Audio output channels	9.2 channels
Dynamic power per channel (4 Ohm)	220 W
Power output per channel (1KHz@6 Ohm)	185 W
Power output per channel (1KHz@8 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	8
Digital audio optical in	3
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	3.5 mm
Multichannel audio output type	Terminals
Speakers connectivity type	Binding post
Audio formats supported	AAC, AIFF, ALAC, DSD, FLAC, MP3, WAV, WMA
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP
Supported radio bands	AM, FM
Preset stations quantity	40
Internet radio services supported	Pandora, TuneIn
Card reader integrated	No
AC input voltage	220-230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.15 W
Power consumption (typical)	310 W
Supported video modes	1080p, 2160p
Cables included	AC

Weight and Dimensions

Depth	441 mm
Width	435 mm
Height	185 mm
Weight	15300 g
