Specifications
Amplifier section
Multi channel simultaneous power output (1 kHz, 1 %, 8 W)
9 ch total .............................................................................................................. 850 W (SC-LX88)/810 W (SC-LX78)
Maximum power output (1 kHz, THD 10 %, 4 W, 1 ch Driven) ............ 370 W (SC-LX88)/350 W (SC-LX78) per channel
Rated power output (1 kHz, 4 W, 1 %, 1 ch Driven) ............................. 260 W (SC-LX88)/250 W (SC-LX78) per channel
Rated power output (1 kHz, 6 W, 1 %, 1 ch Driven) ............................. 220 W (SC-LX88)/210 W (SC-LX78) per channel
Total harmonic distortion ........................................................................................0.04 % (1 kHz, 130 W + 130 W, 8 W)
Guaranteed speaker impedance ..................................................................................................................... 4 W to 16 W
Audio Section
Input (Sensitivity/Impedance)
PHONO MM ..............................................................................................................................................5 mV/47 kW
LINE .......................................................................................................................................................400 mV/47 kW
Output (Level/Impedance)
REC .......................................................................................................................................................400 mV/2.2 kW
Signal-to-Noise Ratio (IHF, short circuited, A network)
LINE .................................................................................................................................................................. 103 dB
Tuner Section
Frequency Range (FM) ....................................................................................................................87.5 MHz to 108 MHz
Antenna Input (FM) ................................................................................................................................ 75 W unbalanced
Frequency Range (AM)
9 kHz step ...................................................................................................................................531 kHz to 1 602 kHz
10 kHz step .................................................................................................................................530 kHz to 1 700 kHz
Antenna (AM) ............................................................................................................................ Loop antenna (balanced)
Video Section
Signal level
Composite Video .................................................................................................................................... 1 Vp-p (75 W)
Component Video .................................................................................... Y: 1.0 Vp-p (75 W), PB/PR: 0.7 Vp-p (75 W)
Corresponding maximum resolution
Component Video .................................................................................................................................1080p (1125p)
Digital In/Out Section
HDMI terminal ......................................................................................................................................... 19-pin (Not DVI)
HDMI output type .............................................................................................................................................. 5 V, 55 mA
HDMI input/MHL terminal ............................................................................................................................. 5 V, 900 mA
USB terminal ..........................................................................................................USB2.0 High Speed (Type A) 5 V, 1 A
USB terminal (SC-LX88 only) .............................................................................................. USB2.0 High Speed (Type B)
iPod terminal ............................................................................................................................................................... USB
ADAPTER PORT terminal ............................................................................................................................... 5 V, 100 mA
WIRELESS LAN ADAPTER terminal .............................................................................................................. 5 V, 600 mA
Integrated Control Section
Control (IR) terminal ....................................................................................................................ø 3.5 Mini-jack (MONO)
IR signal .............................................................................................................................High Active (High Level: 2.0 V)
12 V Trigger terminal ....................................................................................................................ø 3.5 Mini-jack (MONO)
12 V Trigger output type ....................................................................................................................... 12 V, Total 150 mA
RS-232C cable type ........................................................................................................9-pin, cross type, female-female
Network Section
LAN terminal ...............................................................................................................................10 BASE-T/100 BASE-TX
Miscellaneous
Power requirements ............................................................................................ AC 220 V to 230 V / 240 V, 50 Hz/60 Hz
Power consumption ..................................................................................................................................................370 W
In standby ............................................................................................................................................................0.1 W
In standby (HDMI control on) ............................................................................................................................0.3 W
In standby (Network standby on) .......................................................................................................................2.0 W
In standby (HDMI control on, Network standby on) .........................................................................................2.5 W
Auto power down .....................................................................................................15 min, 30 min, 60 min, off (default)
Dimensions ...................................................................................................... 435 mm (W) x 185 mm (H) x 441 mm (D)
Weight (without package)
SC-LX88 ............................................................................................................................................................ 18.0 kg
SC-LX78 ............................................................................................................................................................ 17.6 kg
Number of Furnished Parts
MCACC Setup microphone .............................................................................................................................................. 1
Remote control unit .......................................................................................................................................................... 1
AAA size IEC R03 dry cell batteries .................................................................................................................................. 2
AM loop antenna ............................................................................................................................................................... 1
FM wire antenna ............................................................................................................................................................... 1
Power cord
CD-ROM
Quick start guide
Safety Brochure
Notes
! These specifications are applicable when the power supply is 230 V.
! Specifications and the design are subject to possible modifications without notice, due to improvements.
! This product includes FontAvenue
®
fonts licensed by NEC Corporation. FontAvenue is a registered trademark of
NEC Corporation.
! iOS is a trademark on which Cisco holds the trademark right in the US and certain other countries.
! Microsoft, Windows, Windows Media and Windows Vista are either registered trademarks or trademarks of
Microsoft Corporation in the United States and/or other countries.
! Android and Google Play are trademarks of Google Inc.
! Corporation and product names mentioned herein are trademarks or registered trademarks of the respective
corporations.
