Piper Arrow IV Turbo User Manual

24-02-00
Page 24-10
December 1, 1978
1I5
CHART 2403. TROUBLESHOOTING (ANNUNCIATOR PANEL) (cont)
VAC warning light fails to Bulb burned out. Replace.
operate.
No current to sensor. Check all wire segments and
connections.
Sensor activates at a too Replace.
low setting.
Defective sensor. Replace.
VAC warning light fails to Sensor activates at a too Replace.
extinguish. high setting.
Sensor terminals bridged. Remove material between
terminals.
Defective sensor. Replace.
ALT warning light fails to Bulb burned out. Replace.
operate.
No current from bus to Check all wire segments and
resistor. connections.
ALT warning light fails to Blown fuse. Replace 5 amp fuse near the
extinguish. diode heat sink.
No current from the fuse to Check all wire segments and
the resistor. connections.
Test switch fails to activate Bad switch or connections. Check wires and replace
warning lights. switch if necessary.
Trouble Cause Remedy
PIPER AIRCRAFT
PA-28RT-201 / 201T
MAINTENANCE MANUAL

Piper Arrow IV Turbo Specifications

General

Manufacturer	Piper Aircraft
Model	Arrow IV Turbo
Horsepower	200 hp
Seating Capacity	4
Landing Gear	Retractable tricycle
Range	773 nautical miles
Service Ceiling	20, 000 ft
Fuel Capacity	72 gallons
Propeller	2-blade constant speed
Max Takeoff Weight	2, 900 lb (1, 315 kg)
Stall Speed (Flaps Down)	55 knots
Rate of Climb	1, 000 ft/min
