CHART 601. LEADING PARTICULARS AND PRINCIPAL DIMENSIONS (cont)
MODEL PA-28RT-201 PA-28RT-201T
ENGINE (cont)
Spark Plugs (Shielded):
AC SR86 SR86, S86R, HSR86
Champion REM38E REM38W, RHM38W,
RHM38EP, REM38P,
REM38E, RHM38E
Autolite SH-15 PH26, PH260
Red Seal SE270, SE270P,
SJ270, SJ270P
Spark Plug Gap Setting 0.015 to 0.021 0.15 to 0.19
Firing Order 1-3-2-4 1-6-3-2-5-4
Starter - Prestolite (12-volt) MZ4206 MCL-6501
Alternator:
Chrysler (60 AMP) 3656624 or 4111810 —
Prestolite (60 AMP) ALY-6422 —
Prestolite (65 AMP) ALX-9425
Alternator Voltage Regulator, WICO X16300B X16300B
Alternator Overvoltage Relay, WICO X16799B X16799B
PROPELLER - Constant Speed
Manufacturer McCauley Hartzell
Hub, Model B2D34C213
1
or 2D34C215
2
BHC-C2YF-1-BF
Blade, Model 90DHA-16
1
or 90DJA-14E
2
F8459A-8R
Diameter (in.) 74.0 76.0
Diameter, Minimum (in.) 73.0 75.0
Blade Angle, Low Pitch* 12.5° ± 0.2° 14.4° ± 0.2°
Blade Angle, High Pitch* 29.8° ± 0.5° 29° ± 1.0°
Governor Control and Model Hartzell F-2-7( ) Hartzell E-5 or Wood
ward G210681
Manufacturer Hartzell Hartzell
Hub, Model HC-C2YK-1BF PHC-C3YF-1( )F
Blade, Model F7666A-2R F7663-2R
Diameter (in.) 74.0 76.0
Diameter, Minimum (in.) 72.5 72.0
*MEASURED AT 30 INCH STATION
1 USED ON S/N 28R-7918001 TO 28R-7918306 INCL.
2 USED ON S/N 28R-8018001 AND UP
6-10-00
Page 6-02
Revised: August 17, 1982
