Piper PA-28-161 Maintenance Manual

PIPER AIRCRAFT, INC.
PA-28-161, WARRIOR III
MAINTENANCE MANUAL
PAGE 11
Nov 30/06
1A19
INTRODUCTION
CHAPTER SECTION TITLE GRID NO.
31 INDICATING / RECORDING SYSTEMS 3C15
50 Central Warning Systems
32 LANDING GEAR 3D7
00 General
10 Main Gear
20 Nose Gear
40 Wheels and Brakes
33 LIGHTS 3F3
00 General
10 Flight Compartment
40 Exterior
34 NAVIGATION AND PITOT/STATIC 3G1
10 Flight Environmental Data
20 Attitude and Direction
37 VACUUM 3I11
00 General
10 Distribution
20 Indicating
39 ELECTRICAL / ELECTRONIC PANELS 3J11
10 Instrument and Control Panels
20 Electrical / Electronic Equipment
51 STRUCTURES 4C1
00 General
70 Repairs
80 Electrical Bonding
52 DOORS 4D15
10 Passenger/Crew
30 Cargo
53 FUSELAGE 4E7
20 Main
55 STABILIZERS 4E17
00 General
20 Stabilator
30 Vertical Stabilizer
40 Rudder

Piper PA-28-161 Specifications

General

Manufacturer	Piper Aircraft
Model	PA-28-161 Warrior II
Engine	Lycoming O-320-D3G
Horsepower	160 hp
Seating Capacity	4
Wingspan	35 ft (10.7 m)
Length	24 ft 0 in
Maximum Speed	127 knots
Cruise Speed	122 knots
Maximum Takeoff Weight	2, 325 lb (1, 055 kg)
Fuel Capacity	48 US gallons (182 L)
