Figure 30-3. Electric Prop Deice System Installation (cont)
C234
2
2
1
1
3
3
4
5
6
7
8
9
9
10
11
12
1. PROPELLER DEICER BOOTS
2. SLIP RING
3. CONNECTOR
4. MODULAR BRUSH ASSEMBLY
5. SHUNT
6. TIMER
7. AMMETER
8. PROP DEICE SWITCH
9. LEAD CLIP
10. MOUNTING BRACKET
11. FUSE (5 AMP)
12. CIRCUIT BREAKER
THREE-BLADED INSTALLATION
TWO-BLADED INSTALLATION
PA - 4 4 - 1 8 0 / 1 8 0 T
AIRPLANE MAINTENANCE MANUAL
3 0 - 6 2 - 0 0
Page 30-30
Revised: May 15, 1989
2E10
