Figure 32-16. Removal and Installation of Anchor Bolts
A122
CYLINDER
BODY
PRESS
ANCHOR
BOLT
HOLDING
FIXTURE
STEP A
HOLDING
FIXTURE
ANCHOR
BOLT
STEP B
CYLINDER
BODY
CYLINDER
BODY
PRESS
HOLDING
FIXTURE
HOLDING
FIXTURE
STEP C
STEP D
PA - 4 4 - 1 8 0 / 1 8 0 T
AIRPLANE MAINTENANCE MANUAL
3 2 - 4 4 - 0 3
Page 32-45
Revised: May 15, 1989
2H13
PIPER AIRCRAFT
