GROUND
GROUND
LAMP
GRILL PROBE
TEMPERATURE
CONTROLLER
HEATING
ELEMENT
1650W, 120V
W white
K black
R red
110-120V, 60HZ, 1650W, 3-Prong grounded plug
The Control Board system is an intricate and valuable piece of technology. For protection from power surges
and electrical shorts, consult the wire diagram below to ensure your power source is sufficient for the
operation of the unit.
NOTE: Electrical components, passed by product safety testing and certification services, comply with a
testing tolerance of ± 5-10 percent.
