Pkm WA7-E1214 - Control Panel and Buttons

55
1
Control panel
2
Detergent dispenser
3
Drum
4
Drain pump filter / Cover of the drain pump filter
5
4 adjustable feet
6
Inlet valve for cold water
7
Power supply cable
3.2 Control panel
(Fig. similar: Modifications are possible)
OPERATING BUTTONS:
1
ON / OFF - BUTTON:
Switches the washing machine on or off.
2
START / PAUSE - BUTTON:
To start or pause operation (e.g. changes of the washing
functions, etc.).
