2.2.1 Required minimum distances
For proper ventilation, the appliance requires the following minimum distances
from other appliances, walls, etc.:
NOTICE! Any damage caused by improper ventilation of the
appliance is not subject to the guarantee or the warranty!
2.3 Removing of the shipping bolts
1. The four shipping bolts (A) are on the back of the appliance (s. fig. below left).
2. Unscrew all shipping bolts using the spanner provided in the scope of delivery
(A / s. fig. below right / pleased note the direction of the arrow).
3. Also remove the four spacers (B / s. fig. below left).
During deinstallation of the shipping bolts, the spacers may fall into the housing
of the appliance. In this case, tilt the machine forward carefully and remove the
spacers from the base of the machine.
