4. Ensure that the rubber washer
27
is in the valve
connector. Attach the curved end of the water
inlet hose to the inlet valve of the washing
machine / washer-dryer (s. fig. on the right / 1).
Tighten the water inlet hose firmly (clockwise) to
avoid leakage (s. fig. on the right / 2). Tighten the
hose by hand; do not use pliers or similar tools.
NOTICE! Do not overtighten the water inlet hose. Overtightening of the
water inlet hose can damage the valves.
2.6 Connection of the water drain hose
The water drain hose must be installed at a height between 60 cm and 100 cm
above the floor (s. below; fig. 1, 2, 3 and 4).
The hose outlet must not be installed less than 60 cm above the floor.
The hose outlet must not be installed higher than 100 cm above the floor.
If the water drainage hose is installed on the appliance (as shown in fig. below),
disconnect it from the right bracket only (not from the other brackets / see fig.
below).
Use the holder
28
of the water drain hose to hold the water drain hose in a
curved position (s. fig. below).
27
Depending on model.
28
Equipment depending on appliance model.
