PLA.NET IN-GL55 - Page 3

Dim.
(mm)
IN.
55
IN.
80-80 mix
IN.C.
55+F.Dual
IN.C.
80+F.Dual
IN.F.Dual IN.EL60 IN.FR-4LT IN-LAV
A 730 1030 1150 290 290 810
290 590
B 560 560 560 560 560 525 560 560
C1 20 20 20 20 20 20 20 20
C2 180 180 180 90 90 140 190 200
C3 200 200 200 150 150 150 50 150
C2+C3 380 380 380 240 240 290 240 350
D 530 530 530 530 530 495 530 530
E 700 1000 1120 260 260 260 260 560
A1 200 cm
2
300 cm
2
300 cm
2
A2 200 cm
2
200 cm
2
200 cm
2
A3 200 cm
2
200 cm
2
200 cm
2
TAB. 3
FIG. 1
FIG. 5
A1 Foro aerazione barbecue
A1 Hole ventilation grill
A1 Trou de bentilation grill
A1 Loch Lüftunasaitter
A1
E
D
A2
A3
A2/A3 Fori aerazione vano bombola
A2/A3 Compartment tank ventilation holes
A2/A3 Compartiment des trous de ventilation
A2/A3 Fach tankentlüftungslöcher
Pannello non inammabile
Fireproof panel
Feuerschutzplatte
Panneau ignifuge
MIN 330 mm
135
15 mm
C3
15 mm
560 mm
530 mm
A1
A2
A3
MIN 525 mm
A
A
A
A
B
B
B
B
C
2
C2
C2
C2
C1
C1
C1
C
1
C
3
C3
C3
C3
