Planar PCT2485 - Page 2

Pixel Pitch
0.2715 mm
Refresh Rate
56 to 75 Hz (60 Hz recommended)
Panel Depth
1.8" (44.5 mm)
Dimensions (W x H x D)
22.5" x 13.7" x 1.8" (571.8 mm x 347.0 mm x 44.6 mm)
Dimensions without Stand
22.5" x 13.7" x 1.8" (571.8 mm x 347.0 mm x 44.6 mm)
Display Weight
13.7 lbs (6.2 kg)
Display Weight (w/o stand)
Not applicable. Integrated stand folds into the monitor.
Shipping weight
17.0 lbs. (7.7 kgs.)
Video Inputs
Analog, HDMI, DisplayPort
Audio Output
2 speakers, 1W/ch
Compatibility
Windows® 7, 8 - HID Compliant - no drivers needed for basic touchscreen
operation
External Connections
VGA 15-pin, HDMI 19-pin, DisplayPort 20-pin, 3.5 mm audio in, 3.5mm
headphone out, USB (A to B), USB 2.0 A type x 2, AC power-in
Power Supply
Internal Power Supply (AC power)
Power Requirements
100-240 VAC, 50/60 Hz
Power Consumption (max)
35W typical (<1.0W standby, off)
Operating Temperature
0 to 40°C
VESA Compatible/Location
Built-in 100 mm VESA, back
Service and Support
3-Year Customer First™ Warranty featuring FREE 2-Day Advance Replacement
(US only)
Options / Features
Integrated HD (720p) webcam with microphone; built-in USB Hub -USB 2.0 - x 2,
Kensington® Security Slot
Product Approvals
UL/c-UL, FCC-Class B, CE, TUV/Bauart, RoHS
CI-Black-PN
997-7052-00
CI-White-PN
N/A
In the Box
PCT2485 24" Wide Multi-Touch Monitor, Power Cord, VGA Cable, HDMI Cable,
USB Cable (A to B), Audio-in Cable, User's Guide, Cleaning Cloth, Stylus, Cable
Wrap
UPC
8 10689 07052 8
For more information, please visit www.planar.com
Specifications are subject to change without notice.
Specification Report Date: 1/5/2014
© Copyright 2014 Planar Systems, Inc. All rights reserved
