INTRODUCTION
UN LOA DING THE MA RKER
25
WARNING!
Always make sure that the marker is OFF with a barrel blocking device installed and
that no paintballs are in the marker or loader before attaching an air system.
Compressed air and nitrogen systems can be extremely dangerous if handled or
used incorrectly.
Only attach an air system certified for use within the country of use.
Never add lubricants or grease into the fill adaptor of the air system regulator.
Ensure that all screws are tightened and no parts are loose before installing an air
system.
Do not pressurise the marker without the bolt system correctly installed, as high
pressure gas will be emitted.
Do not install a compressed air system or load paintballs into the marker until you
feel confident with your ability to handle the marker safely and responsibly.
FIG.1
A ENSURE THAT A BARREL BLOCKING DEVICE IS FITTED.
To prevent accidentally firing a paintball when unloading.
Remove barrel blocking device after step F
.
B SWITCH THE MARKER OFF.
C DE-GAS THE MARKER.
Push in and hold the POPS button and slide the POPS
bonnet away from the POPS body.
D REMOVE THE PRE-SET AIR SYSTEM.
Rotate air system counter-clockwise from the POPS body.
E LOOSEN THE CLAMPING FEEDNECK.
Open the feedneck lever away from the feedneck.
Rotate the feed wheel counter-clockwise.
F REMOVE THE LOADER.
If the feedneck is too tight, loosen the feed wheel.
G REMOVE THE S63 BARREL FROM THE MARKER BODY.
Rotate the barrel counter-clockwise to remove.
H DISASSEMBLE THE S63 BARREL.
Rotate the barrel tip clockwise to remove.
Slide the PWR Insert out from the back section.
! IMPORTANT! To switch OFF/ON, see page 08.
! IMPORTANT! Always de-gas before unloading.
! IMPORTANT! Always remove air system before unloading.
! IMPORTANT! Always remove any paintballs from the breech
of the marker once the loader has been removed.
! IMPORTANT! The barrel tip is reverse threaded so unscrew it
CLOCKWISE.
