PLANET ECLIPSE CS3 - Page 63

C S 3
TECHNICAL
BO LT ASS EMBLY
63
1 Bolt bonnet
2 Switch body cap screws (x4)
M2.5 x 8 cap head socket
3 M2.5 spring washers
4 Bolt pin
5 Switch body cap
6 4 x 1 NBR70 (x3)
7 5mm ball bearing
8 Plunger
9 #010 NBR70
10 Switch body
11 #021 NBR70 (x3)
12 20 x 1.2 NBR70 (internal)
13 Switch
14 #016 NBR70 (x2)
15 Spring guide
16 Spool spring
17 Joiner
18 #012 NBR70 (x2)
19 Spool
20 #011 NBR70
21 20 x 1.2 NBR70 (internal)
22 Bolt guide
23 #017 NBR70
24 #013 NBR70 (x3)
25 6 x 1.5 NBR70 (internal)
26 14 x 2 NBR70
27 #015 NBR90
28 Hard bolt
29 #013 NBR70
30 Can
31 #020 NBR70
32 #017 NBR70 (internal)
33 Cure FT bolt tip
34 14 x 2 NBR70
35 #015 NBR90
36 #013 NBR70
37 Cure FT bolt
