TECHNICAL
PAR TS LIS T
65
FIG.1
A Locating clamping feed tube assembly
B Marker body
C Bolt bonnet
D Drivetrain assembly
E Rubber detent
F Breech Sensor (BS)
G Light pipe
H Rear frame screw
I Navigation console
J Modular Marker Electronics (MME)
K OLED display
L Push On Purge System (POPS) body
M Push On Purge System (POPS) bonnet
N Frame assembly
O Trigger assembly
P Solenoid assembly
Q Front frame screw
R AA Battery housing (foregrip)
S AA battery orientation guide
T Battery retainer (locking tabs)
U Foregrip rubber sleeve
V Regulator assembly
