Planet SGS-6341-24T4X User Manual

59-8
59.12 webportal nas-ip
Command:
webportal nas-ip <ip-address>
no webportal nas-ip
Function:
Configure IP source address for communicating between accessing device and portal server.
Parameter:
<ip-address>: IP source address for communicating between accessing device and portal server in
dotted decimal notation, it must be the legal unicast address.
Command Mode:
Global Mode.
Default:
Do not configure the specific IP source address, the communication between accessing device and
portal server uses the IP address of the sending interface.
Usage Guide:
The configured source address must be the local IP address, or else it maybe not process the
packet communication with portal server. It is recommended to use the loopback interface address
as the source address to avoid the return packet is unreachable when the physical interface is down,
and nas-ip should be configured in web portal. The no command deletes IP source address for
communicating between accessing device and portal server.
Example:
Configure IP source address as 10.1.1.1 for communicating between accessing device and portal
server.
switch(config)#webportal nas-ip 10.1.1.1
59.13 webportal redirect
Command:
webportal redirect <ip>
no webportal redirect
Function:
Configure HTTP redirection address of web portal authentication.
Parameter:
<ip> is IP address of portal server.
Command Mode:

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
