Planet SGS-6341-24T4X User Manual

70-7
name is not integrity (such as sina), the switch can add suffix automatically, after that, address
mapping can run, the domain name suffix can be configured no more than 6. The first configured
domain name suffix will be added first.
Example:
To configure domain name suffix of com.
Switch(config)# ip domain-list com
70.12 ip dns server
Command:
ip dns server
no ip dns server
Function:
Enable/disable DNS SERVER function.
Command Mode:
Global Mode.
Default:
Disabled by default.
Usage Guide:
After the DNS SERVER function is enabled, the switch will be able to receive and handle DNS
Requests from the clients by looking up locally or forward the request to the real DNS server.
Example:
Configure to enable the dns server function of the switch.
Switch(config)#ip dns server
70.13 ip dns server queue maximum
Command:
ip dns server queue maximum <1-5000>
no ip dns server queue maximum
Function:
Configure the max number of client information in the switch queue.
Parameter:
<1-5000> the value can be 1－5000.
Command Mode:

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
