Planet SGS-6341-24T4X User Manual

11-40
packets except OAMPDU packets
received are returned to their
sources along the ways they come.
Loopback Supported
Whether support remote loopback: YES for support and NO for not.
Unidirectional Support
Whether support unidirectional transmission: YES for support and NO
for not.
Link Events
Whether support general link events: YES for support and NO for not.
Remote Failure
Whether support severe link events (remote failure indication): YES for
support and NO for not.
Link Fault
Whether occur a Link Fault event: 0 for no and 1 for yes.
Dying Gasp
Whether occur a Dying Gasp event: 0 for no and 1 for yes.
Critical Event
Whether occur a Critical Event: 0 for no and 1 for yes.
Max_OAMPDU_Size
The maximum length of OAMPDU is supported.
OAMPDU
Show the number of the OAMPDU packets sent and received which is
the sum of three kinds of packets.
Information
Show the number of the Information OAMPDU packets sent and
received
Event Notification
Show the number of the Event Notification OAMPDU packets sent and
received
Loopback Control
Show the number of the Loopback Control OAMPDU packets sent and
received
Display detailed information of remote OAM entity for Ethernet 1/0/2
Switch#show ethernet-oam remote interface ethernet1/0/2
Ethernet1/0/2 oam remote Information：
Remote_Mac_Address=0003.0f19.3a3e
local _mode=active
--------------------------------------------------------------------------
local_pdu=INFO
local_mux_action=FWD
local_par_action=DISCARD
Loopback Supported=YES
Unidirectional Support=NO
Link Events=YES
Remote Failure=YES
Max_OAMPDU_Size=1518
--------------------------------------------------------------------------
OAM Remote Flags Field：

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
