Planet SGS-6341-24T4X User Manual

11-41
Link Fault=0 Dying Gasp=0 Critical Event=0
Field
Description
Remote_Mac_Address
MAC address of remote OAM entity
local _mode
Working mode of Ethernet OAM:
active, the port is set as active mode;
passive, the port is set as passive mode.
local_pdu
The way in which the local end processes Ethernet OAMPDUs:
RX_INFO, the port only receives Information OAMPDUs and does not
send any Ethernet OAMPDUs.
LF_INFO, the port only sends Information OAMPDU packets without
Information TLV and with their link error flag bits being set.
INFO, the port only sends and receives Information OAMPDU packets.
ANY, the port sends and receives any OAMPDU packets.
local_mux_action
Working mode of the local transmitter:
FWD, the port can send any packets;
DISCARD, the port only sends OAMPDU packets and discards others.
local_par_action
Working mode of the local receiver in the following:
FWD, receiving any packets is allowed;
DISCARD, only OAMPDU
packets is received while others are
discarded;
LB, OAM remote loopback is enabled on the port. In this case, all the
packets except OAMPDU packets
received are returned to their
sources along the ways they come.
Loopback Supported
Whether support remote loopback: YES for support and NO for not.
Unidirectional Support
Whether support unidirectional transmission: YES for support and NO
for not.
Link Events
Whether support general link events: YES for support and NO for not.
Remote Failure
Whether support severe link events: YES for support and NO for not.
Max_OAMPDU_Size
The maximum length of OAMPDU is supported.
Link Fault
Whether occur a Link Fault event: 0 for no and 1 for yes.
Dying Gasp
Whether occur a Dying Gasp event: 0 for no and 1 for yes.
Critical Event
Whether occur a Critical Event: 0 for no and 1 for yes.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
