Planet SGS-6341-24T4X User Manual

28-64
are received by the interface). The no command sets the additive suboption2 (remote ID option)
format of option 82 as standard.
Parameters:
standard means the default VLAN MAC format. <remote-id> means the remote-id content of
option 82 specified by users, its length can not exceed 64 characters.
Command Mode:
Global Mode
Default Settings:
Use standard format to set remote-id of option 82.
User Guide:
The additive option 82 information needs to associate with third-party DHCP server, it is used to
specify the remote-id content by users when the standard remote-id format can not satisfy server’s
request.
Example:
Set the suboption remote-id of DHCP option82 as street-1-1.
Switch(config)#ip dhcp relay information option remote-id street-1-1
28.5 ip dhcp relay information option remote-id format
Command:
ip dhcp relay information option remote-id format {default | vs-hp}
Function:
Set remote-id format of Relay Agent option82.
Parameters:
default means that remote-id is the VLAN MAC address with hexadecimal format, vs-hp means that
remote-id is compatible with the remote-id format of HP manufacturer.
Command Mode:
Global mode
Default Setting:
default.
User Guide:
The default remote-id format defined as below:
Remote option
2 6
MAC
1 byte 1 byte
6 byte
type
Length

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
