Planet SGS-6341-24T4X User Manual

36-233
advertise: Advertise this area
not-advertise : Not advertise this area
If both are not set, this area is defaulted for advertising
Default:
Function not configured.
Command Mode:
OSPFv3 protocol mode
Usage Guide:
Use this command to aggregate routes inside an area. If the network IDs in this area are not
configured continuously, a summary route can be advertised by configuring this command on ABR.
This route consists of all single networks belong to specific range.
Example:
Switch # config terminal
Switch (config)# router ipv6 ospf
Switch (config-router)# area 1 range 2000::/3
36.3 area stub
Command:
area <id> stub [no-summary]
no area <id> stub [no-summary]
Function:
Define a area to a stub area. The “no area <id> stub [no-summary]” command cancels this
function.
Parameter:
<id> is the area number which could be digits ranging between 0～4294967295, and also as an
IPv4 address.
no-summary:
The area border routes stop sending link summary announcement to the stub area
Default:
Not defined
Command Mode:
OSPFv3 protocol mode
Usage Guide:
Configure area stub on all routes in the stub area. There are two configuration commands for the
routers in the stub area: stub and default-cost. All routers connected to the stub area should be
configured with area stub command. As for area border routers connected to the stub area, their

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
