Function:
Configure multicast source control access-list used on interface, the “no ip multicast source-control
access-group <5000-5099>” command deletes the configuration.
Parameter:
<5000-5099>: Source control access-list number.
Command Mode:
Interface Configuration Mode
Usage Guide:
The command configures with only enabling global multicast source control. After that, it will match
multicast data message imported from the interface according to configured access-list, such as
matching: permit, the message will be received and forwarded; otherwise the message will be
thrown away.
Example:
Switch (config)#interface ethernet
Switch (Config-If-Ethernet )#ip multicast source-control access-group 5000
Switch (Config-If-Ethernet )#
Switch(router-msdp)#default-rpf-peer 10.0.0.1 rp-policy 10
44.8.9 multicast destination-control
Command:
multicast destination-control
no multicast destination-control
Function:
Configure to globally enable IPv4 and IPv6 multicast destination control, after configuring this
command, IPv4 and IPv6 multicast destination control will take effect at the same time. The no
operation of this command is to recover and disable the IPv4 and IPv6 multicast destination control
globally.
Default:
Disabled.
Command Mode:
Global Configuration Mode.
Usage Guide:
Only after globally enabling the multicast destination control, the other destination control
configuration can take effect; the destination access list can be applied to ports, VLAN-MAC and
SIP. After configuring this command, IGMP-SNOOPING and IGMP will match according to the rules
mentioned above when they try to add ports after receiving IGMP-REPORT.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
