48-18
Function:
Set the global max number of IPv4 controlled/trusted users.
Command Mode:
Global Configuration Mode.
Default Settings:
The max IPv4 user number supported by the switch is 128.
Usage Guide:
This command is for setting the max IPv4 user number supported by the switch, ranging from 1 to
700. This number limit is the sum of dot1x user number and the trusted user number added by ip
dhcp snooping binding user-control.
Example:
Set the max IPv4 user number globally.
Switch(config)#user-control limit ipv4 100
48.26 user-control limit ipv6
Command:
user-control limit ipv6 <count>
Function:
Set the global max number of IPv6 controlled/trusted users.
Command Mode:
Global Configuration Mode.
Default Settings:
The max IPv6 user number supported by the switch is 256.
Usage Guide:
This command is for setting the max IPv6 user number supported by the switch, ranging from 1 to
1400. This number limit is the sum of the trusted user number added by ipv6 dhcp snooping
binding user-control and ipv6 nd snooping user-control.
Example:
Set the max IPv6 user number globally.
Switch(config)#user-control limit ipv6 100

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
