Planet SGS-6341-24T4X User Manual

49-1
Chapter 49 Commands for the Number
Limitation Function of MAC and IP in
Port, VLAN
49.1 debug ip arp count
Command:
debug ip arp count
no debug ip arp count
Function:
When the number limitation function debug of ARP in the VLAN, if the number of dynamic ARP and
the number of ARP in the VLAN is larger than the max number allowed, users will see debug
information. ”no debug ip arp count” command is used to disable the number limitation function
debug of ARP in the VLAN.
Command Mode:
Admin Mode.
Usage Guide:
Display the debug information of the number of dynamic ARP in the VLAN.
Examples:
Switch#debug vlan mac count
%Jun 14 16:04:40 2007 Current arp count 21 is more than or equal to the maximum limit in vlan
1!!
%Jun 14 16:04:40 2007Arp learning will be stopped and some arp will be delete !!
49.2 debug ipv6 nd count
Command:
debug ipv6 nd count
no debug ipv6 nd count
Function:
When the number limitation function debug of neighbor in the VLAN, if the number of dynamic
neighbor and the number of neighbor in the VLAN is larger than the max number allowed, users will
see debug information. ”no debug ip neighbor count” command is used to disable the number
limitation function debug of neighbor in the VLAN.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
