OTHER INSTALLATION ALTERNATIVES
32 Planmeca Intra X-ray unit
Installation manual
NOTE The ceiling arm shaft can be locked temporarily to ease the installation of
the unit.
Intra ceil.adap.assy 7 050397
Ceiladap6.eps
Fastening screw
Tighten this locking screw
Tighten firmly
