5.0/5.7L Fuel Metering System 3A - 3

MEFI 4 - PCM

Figure 3-2 - Typical Fuel Control Cell (FCC)

Figure 3-1 - Fuel Metering System (Typical)

Figure 3-3 - Low Pressure Fuel Pump

FUEL

TANK

PRESSURE

REGULATOR

FUEL

FILTER

LOW-

PRESSURE

FUEL

PUMP

FUEL

CONTROL

CELL

FUEL RAIL ASSEMBLY

ENGINE

Fuel Control Cell Fuel System
