3A - 12 Fuel Metering System 5.0/5.7L
MEFI 4 - PCM
Fuel Rail Assembly
1
2
3
4
5
6
7
8
9
Legend
(1) Fuel Rail Attaching Stud
(2) Fuel Pressure Connection Cap
(3) Fuel Rail Assembly
(4) Fuel Injector O-Ring
(5) Fuel Injector Assembly
(6) Fuel Injector Retaining Clip
(7) Fuel Pressure Regulator
(8) Fuel Pressure Regulator Retaining Clip
(9) Fuel Pressure Regulator Vacuum LIne
