Plotmaster HUNTER Series - Page 14

Page 14 of 22
PLOTMASTER™ HUNTER 400
Recommended use: ATV---500CC or Larger---4 Wheel Drive
Unit Includes:
 Unique Down Pressure System for the 1 point Hitch, Disc Harrow, Electric Versa Seeder,
Linear Lift System (18 second retraction/extension), Cultipacker/Drag with Metal Grating.
(Units can also be converted for use with Tractor 3 PT. Cat. 1) PT# H-PHC-101-08
Dimensions:
 Folded Length: 68”
 Hitch Extended: 99”
 Machine Width: 48”
 Wheel Width: 58”
 Overall Height: 40” (Lowered Position)
 Overall Height: 48” (Raised Position)
 Weight: 626#
Disc Harrow:
 12 Heavy-Duty 16” Notched Disc with Sealed Bearings
 Maximum cutting width: 48”
Versa Seeder System:
 New, Patent-Pending Versa Seeder, Reverse Auger Brush System designed to
plant all types of seeds and seed blends.
