(H. Electric Seeder)
The Seeder is where your seed is dispensed from;
The H-300 capacity is 40# of seed and the H-400 capacity is 50# of seed.
(Plotmaster “DOES NOT” recommend lime or fertilizer be dispensed through this seeder!)
(I. Seeder Motor) (PT# SA-29-06-A)
The Electric Seeder Motor is activated by the Control Boxes ON/OFF switch. This motor drives the
spiral brush that dispenses the seed.
(Versa Seeder)
(J. Drag Bar Receiver)
This receiver is located on the rear of the unit and is secured by a 1/2 x 3 hitch pin with clip. This is
where the Drag Bar and Metal Grating pin into the rear of the unit.
(K. Drag Bar w/Metal Grating)
The Drag bar and/or Metal grating is used for either leveling uneven areas or for covering smaller seed
that only require a minimal amount of coverage to germinate.
(L. Metal Grating)
The H-300 Grating is 45” W and 24”L ____ The H-400 Grating is 45” W and 24”L
(M. Control Box) NOT Shown (PT# HE-2006)
The Control Box is used to raise and lower the unit and to switch the seeder motor on and off.
Replacement Fuse—30 AMP SLOW BLOW FUSE—Switches can be bought separately.
(N. Tabs for 1-point and 3-Point Hook-up for ATV/UTV & Tractor) *New Design*
(O. Rest for Cultipacker Roller) *New Design*
(P. Splatter Plate for Seed Disbursing) *New Design*
The Splatter Plate can be adjusted vertical/horizontal or anywhere in between for desired disbursement
of seeds being planted.
(Q. Tension for Cultipacker Roller)
The Roller is designed to pack the soil for greater seed to soil contact. The Spring/Chain is designed to
add even more compaction, if desired.
(R. Serial# Tag for your Plotmaster)
(S. Canister for Manual) *New Design*
