무선사양(주파수)
WLAN
• 802.11b/g/n : 2412~2472MHz
• 802.11a/n: 5180~5240, 5260~5320, 5500~5620,
5745~5805MHz
Bluetooth
• 1~3Mbps: 2402~2480MHz
• LE: 2402~2480MHz
WCDMA
• Band 1 (transmit): 1922.8~1977.2MHz
(receive): 2112.8~2167.2MHz
LTE
• Band 3 (transmit): 1715~1785MHz
(receive): 1810~1880MHz
• Band 5 (transmit): 824~849MHz
(receive): 869~894MHz
Resetting the device
Reboot
Press and hold power key for 3 seconds and select
Reboot on options to reboot the device.
Factory reset
Follow the process by tapping next button to complete
factory reset.
<Caution>
• Back up all data - personal, application settings,
account information and etc. before performing factory
reset as it causes all data delete.
Setting the date and time
Go to below route to set date and time.
Access to above route and alter the following
settings according to user’s decision.
• Set date
• Set time
• Select time zone
• Use 24-hour format
• Select date format
Offline
Tel: 02-3397-7870
Fax: 02-3397-7872
Address: B-9F Kabul Great Valley, 32, Digital-ro 9-gil,
Geumcheon-gu, Seoul, Korea 08512
Online
Website:
http://www.pointmobile.co.kr/
E-mail: gmchoi@pointmobile.co.kr
User guides supports detailed information on safety
& regulations of device and accessories.
Due to the possibility of electric wave interference
by device, no support on life safety.
Technical support & A/S
User guides
Certification
Equipment name: Wireless data communication
system device
(Wireless Access System device with
Wireless LAN)
Model: PM80
Trade name of certified: POINT MOBILE CO.LTD
Manufacturer/ Country of origin: POINT MOBILE
CO.LTD/ China
Production date: 2015.12.XX
Certification No. : MSIP-CMM-PM1-PM80W
Connecting USB data Sync cable
Connect to PC and transfer data in Micro SD card/ device
storage with I/O USB data Sync cable.
Connecting –connect USB cable to USB port of PC and I/O
connector.
– Tab media device connection on notification panel
of status bar.
– Select file transfer on pop up window.
Disconnecting – Tab to show notification panel and select
media device connection.
– Select media device (MTP) and disable the
connection.
Connecting to PC
Settings -> back up and reset -> Factory reset ->
Reset phone
Settings -> Date and time -> Uncheck automatic date & time,
Uncheck automatic time zone
Standard features
Item Specifications
Model PM80
Operating
System
Android 5.0 or higher(GMS/CTS certified)
Software Tools and Demos
Micro-Processor Qualcomm 8016 1.4GHz Quad Core
Memory 1GB RAM X 8GB Flash(Upgradable)
Memory
extension
User accessible Micro SD memory card slot.
Display 5.0” Wideviewing angle IPS(1280 X 720 pixels)
Data capture
options
2D engine : SE4710
Keypad Touch screen & Front 4 hard keys
Audio Built-in microphone and speaker
I/O High speed USB 2.0 from cradle (or I/O cable)
Weight Below 270g
Wifi 802.11 a/b/g/n(Up to 150Mbps)
Bluetooth
Bluetooth v4.x, class2
NFC/RFID
13.5593MHz
Serial(RS232C) 9600bps,19.2kpbs,38.4kbps,57.6kbps,115.2kbps
USB USB HS 2.0 OTG Support via I/O connector
Battery Li-ion battery 3.8V / 3000 mAh / 11.4 Wh
Adaptor Output: 5V / 2A, Input: 100-240V~50/60Hz 0.4A
Charger 5V input through DC port.
Battery Capacity: 3000mAh – Less than 4hrs.
20ºC ~ 60ºC
Rain/dust
protection
IP67
Li-ion battery follows varied regulations in each
region/ country. Accordingly, recycle or disuse li-ion
battery properly. Do not leave or store it in fire or
heat it or disassemble or short circuit it.
Prevent plug and consent from dust and dirt to
keep them clean. Improper storing or misuse may
cause fire, electric shock, etc.
Warning
Do not allow any strong pressure or impact on the
touch screen. Do not touch any interior liquid from
LCD panel breakage that may cause skin irritation.
Use only approved AC/DC power adaptor
provided with device or from distributor.
Disapproved products may cause unexpected
problems as fire, electric shock, etc.
Disapproved modification or repair is not
guaranteed. Inquire to distributor for any
troubleshooting.
HANDY TERMINAL
Quick start guide
PM80
• For more details of product information and user
guide, please refer to our website
(
www.pointmobile.co.kr)
Allowed to use in all area.
Please use the device at 1 cm or more distance
away from your body.
