1.
Take out the first drawer of the refrigerator and find the connector below
the tank.
water pipe connector
locking clip
water pipe connector
water pipe
first layer of drawer
collet
2.
Remove the blue locking clip on either side of the connector.
locking clip
3.
With one hand, press the collet in front of the water pipe joint in the
direction of the arrow, and the other hand pulls out the water pipe.
collet
4.
After standing for 5-10s, follow the opposite steps to install and restore.
Attention that the pipe has to push firmly with the connector.
