WARNING:
▪
THIS PRODUCT IS INTENDED FOR USE IN LAWN CARE AND HOME
APPLICATIONS.
▪
DO NOT TOW BEHIND A VEHICLE OR USE ON A HIGHWAY OR IN ANY HIGH
SPEED
APPLICATION.
▪
THIS PRODUCT HAS BEEN DESIGNED FOR OFF-ROAD USE
ONLY.
Transporting Loads Safely
•
Stopping distance increases with speed and weight of load. Travel slowly and allow extra time
and distance to stop.
•
Excessive load can cause loss of traction and loss of control on slopes. Reduce payload weight
when operating on slopes.
•
Never allow children or others in or on equipment.
•
Do not attach the Utility Cart to any powered vehicle.
•
Follow the manufacturer’s recommendations for weight limits.
•
Do not turn sharply. Use additional caution when turning or operating under adverse surface conditions.
Keep Riders off Utility
Cart
•
Keep riders off of the Utility Cart.
•
Riders are subject to injury, such as being struck by objects or being thrown off the attachment
during sudden starts, stops and turns.
•
Riders obstruct the operator’s view, resulting in the Utility Cart being used in an unsafe manner.
QTY
PART NO.
DESCRIPTION
1
102612
BASE, CURVED
1
105341
INSTRUCTION, CART
2
102595
20" SPOKED WHEELS
1
104257
REMOVABLE LABEL, UTILITY CART
1
105342
INNERPACK, UTILITY CART (INCLUDE THE FOLLOWING)
1
105339
HANDLE, TOP, UTILITY CART
1
102609
ASSY, TUBE CAP, LEG
1
102599
WELDMENT, AXLE, 20" HANDCART
2
105344
ASSY, HANDLE, SIDE, UTILITY CART
1
102601
KIT, HARDWARE, HAND CART (INCLUDES THE FOLLOWING)
2
102201
SPRING COTTER PIN
11
102605
SCREW,5/16-18 X 1.75 THMSCZ
5
102607
WASHER, .75 USS SAE STANDARD YZ
12
102606
5/16 - 18 THIN NYLOCK CZ
12
102035
WASHER, 5/16 WIDE FLAT
3
101473
SCREW, 1/ 4-20 X 1.50 PTH GR2
3
101163
NUT, 1/4-20 NYLOCK
PARTS LIST
