72
FEATURES AND CONTROLS
Batteries
12-Volt Terminal Board Connections
Remove the upper dash to access the 12-volt
terminal board. See page 104.
Always make sure that all 12-volt electrical
accessories are grounded directly to the negative
(-) post on the terminal board. Never use the
chassis or body as a ground connection.
Use the positive (+) terminal only for accessories
that require constant power (when the ignition key
is off).
Use the accessory (ACC) terminal for accessories
that require power only when the ignition key is
on.
NOTICE: To avoid draining the battery system, always install an accessory exactly as stated in the
provided installation instructions.
