107
MAINTENANCE
Fuse and Relay Recommendations
NOTICE: 12V fuses must not be used in 48V applications. 48V fuses must not be used in 12V
applications. Always install fuses with the recommended amperage to avoid damage to the
electrical system.
Standard 12V Fuses
Application Size Location
Drive; Constant;
Internal Lighting
5 amp 12V Fuse Center
Horn; Display 10 amp 12V Fuse Center
Wiper; ACC; Lights 15 amp 12V Fuse Center
VCM 20 amp 12V Fuse Center
Chassis 30 amp 12V Fuse Center
Optional 12V Fuses
Application Size Location
Lithium-ion 5 amp Lithium-ion Harness
Beacon Light 7.5 amp Beacon Harness
Security Light 7.5 amp Security Light
Harness
Stereo 10 amp Stereo Harness
EPS 30 amp EPS Harness
Standard 48V Fuses
Application Size Location
Motor Controller/
BMC
5 amp 48V Fuse Center
DC-DC; Charger 30 amp 48V Fuse Center
Optional 48V Fuses
Application Size Location
Lithium-ion 5 amp Lithium-ion Harness
Heater Heating
Element
30 amp Heater Harness
Defrost 30 amp Defrost Harness
