42
FEATURES AND CONTROLS
Digital/Analog Gauge
Indicator Lamps
Lamp Indicates Condition
Vehicle Speed When standard mode is selected, speed displays in miles per hour.
When metric mode is selected, speed displays in kilometers per hour.
Brake
Indicator
This lamp illuminates when the park brake is engaged or when a brake
system failure has occurred. See page 43.
Direction
Indicators
A direction indicator flashes when a turn signal is active.
Low Beam This lamp illuminates when the headlamp switch is set to low beam.
High Beam This lamp illuminates when the headlamp switch is set to high beam.
Seat Belt When the key is turned on, the seat belt indicator lamp will illuminate if the
driver’s seat belt is not fastened. The lamp is a reminder to the operator to
ensure all riders are wearing seat belts before operating.
To Next Page
