FAST M-10 Rear Suspension Adjustments
Initial M-10 Suspension Set-up Chart
NOTE: These positions are only preliminary. Experimentation should
follow initial set-up to obtain optimum results. Refer to the sus-
pension troubleshooting decal for additional set-up tips.
*Might prefer optional spring (rear track). Refer to the list on page 49.
INITIAL SET-UP REFERENCE CHART
This chart is a guideline to be used for initial suspension set-ups.
Your set-up may vary based on your desired riding style.
FRA Position Dimension
B
Dimension
C
Rider weight
with full
riding gear
SOFT FIRM Rear Spring
Preload
Crossover
Tube Length
Limiter/Ski
Pressure
Settings
Settings
In mm In mm Light Firm
100 lbs. 1 1 1/4 0 0 5 5/8 143 4/4 3/3
125 lbs. 1 1 1/2 0 0 5 13/16 148 4/4 3/3
150 lbs. 1 1 1/2 5/16 8 5 13/16 148 4/4 3/3
175 lbs. 1 1/2 2 5/16 8 5 13/16 148 4/4 3/3
200 lbs. 2 2 1/2 5/16 8 5 3/4 146 4/4 3/3
225 lbs. 2 1/2 3 5/16 8 5 5/8 143 4/4 3/3
250 lbs. 3 3 1/2 5/16 8 5 9/16 141 4/4 3/3
275 lbs. 3 3 1/2 1/2 13 5 7/16 138 4/4 3/3
300 lbs. 3 3 1/2 1/2 13 5 3/16 132 4/4 3/3
325 lbs.* 3 3 1/2 5/8 16 5 3/16 132 4/4 3/3
350 lbs.* 3 1/2 4 5/8 16 5 3/16 132 4/4 3/3
375 lbs.* 4 5 7/8 22 5 3/16 132 4/4 3/3
