46
THE PERFECT FIT
FAST M-10 Rear Suspension Adjustments
Static Sag and Ride Height Settings
Ski Pressure
Ski pressure is set at the factory t o deliver the optimum balance
between ride and handling. If a rider prefers more ski pressure for
improved steering performance, adjustments can be made to the front
limiter strap and front arm m ount.
1. Determine if t he rider
prefers comfort or
control. Lean toward the
#4 setting for comfort
and toward the #3
setting for aggressive
riding.
2. F or full hole
adjustments,
remove the 5/16”
nut and flat washers
from the lower
attachments of the
limiter straps and relocate
the straps to the desired position
(i.e. m ove from position 4 t o 3). Replace the nut and washer.
Tighten securely.
3. For half-hole i ncrements (such as 3/4), the limiter straps have slots
at the upper pinch bolt. These slots allow the bolts to be loosened
(rather than removed) for hal f--step adjustments. Re-- tighten the
pinch bolts.
4
3
2
1
3
4
2
